| Frequency Range | 698-960 MHz, 1710-2700 MHz |
| Gain | 4/6 dBi |
| V.S.W.R | <1.5 |
| Radiation | Omni Direction |
| Horizontal Beam width | 2.4GHz 5dBi dipole antenna |
| Wireless Performance | 360º |
| Vertical Beam width | 18º |
| Polarization | Vertical |
| Maximum Input Power | 100 W |
| Impedance | 50 ohm |
| Connector | N Female |
| Antenna Material | Fiberglass |
| Mount type | Pole |
| Diameter of Installation Pole | Ø30 – Ø50 mm |
| Dimensions | Ø63 x 220 mm |
| Weight | 1.2 kg |
| Operating Temperature | -40ºC – 70ºC |
| Rated wind velocity | 60 m/s |
